SINOTRUK Howo 6×4 Water Truck
According to clients’ requirements, we can customize different loading capacity and volume.
Howo 6×4 Water Tank Truck
- Condition: Brand New
- Tyre Quantity: 10 tyre
- Engine Power:380hp, 400hp
- Driving Type: 6×4
- Cubage: 20000 L
We are always ready to face the most severe working conditions.
Thanks to its robust and durable body, HOWO truck has extraordinary performance in construction, mining and other application scenarios.
In the harsh working environment, HOWO is always ready to meet the severe test.
Overview
Howo Water Tanker Truck: Your Reliable Partner for Jobsite Water Management
Whether your job site requires dewatering, dust abatement, or general non-potable water supply, the Howo Water Tanker Truck is engineered to get the job done.
Available in various models, every one of our water tanker trucks is built with rugged reliability and uncompromising durability to meet the demands of today’s contractors head-on.
Choose Howo for efficient and dependable water solutions, ensuring your operations run smoothly without interruption.
Parameters
| Vehicle type | Whter Tank |
|---|---|
| Drive type | 6x4 |
| Cab | HW76 with AC One sleeper |
| Engine | WP12. Euro 2 |
| Clutch | Φ430 Diaphragm spring clutch, hydraulic operating with air assistance |
| Transmission | HW19710, 10F /2R |
| Front axle | VGD95, 9.5 Ton Drum brake |
| Rear axle | MCX16ZG |
| Steering System | ZF power steering, model ZF8118, hydraulic steering with power assistance |
| Brake System | Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake |
| Electrics | Single wire, 24 V, negative grounded; Alternator: 1540W; Start Motor:7.5kW;Battery:2*12V/165Ah |
| Tyre | 12.00R20,315/80R22.5,13R22.5 etc. |
| Fuel Tank (L) | 300L Diesel Tank |
| Max. Speed (km/h) | 75 |
| Water tank volume | 20000 liters, tank thickness is 5 mm, seal is 5 mm Equipped with pump and nozzle |
If you are interested in this Howo Water Truck welcome to leave your message!
We will provide more details, quotations, catalogs, drawings, and videos for you!
GET NOW!
Recommed Products
improve your business
Let’s discuss how we can help you.
R Trucks reference configuration
The catalogue above includes configuration variants. The tables below are references for comparing offers. Confirm the actual engine, gearbox, axles, dimensions, equipment and steering side in writing, and match the inspection record to the truck supplied.
| Engine | SINOTRUK WD615.95E · 375 hp |
|---|---|
| Drive | 6x4 |
| Tank capacity | 20,000 L (20 m³) |
| Spraying | Front spray · rear sprinkler · water cannon |
| Pump | Self-priming booster pump |
| Driver position | Left- or right-hand drive |
|---|---|
| Engine | SINOTRUK WD615.95E, 6-cylinder, 375 hp |
| Gearbox | SINOTRUK HW19710 manual, 10 forward / 2 reverse |
| Clutch | Ø430 mm diaphragm |
| Front axle | SINOTRUK HF9 |
| Rear axles | SINOTRUK HC13 double reduction, ratio 4.7 |
| Steering | ZF-technology power steering |
| Wheelbase | 3775 + 1400 mm |
| Frame | Double frame, 940–850 × 300 mm, 8 + 8 mm |
| Suspension | Leaf springs, 12 front / 14 rear |
| Fuel tank | 300 L aluminium alloy |
| Tyres | 12R22.5 |
| Brakes | Dual-circuit air service brake · spring parking brake · engine exhaust brake |
| Water tank | 20 m³ steel tank, bottom 6 mm, top 4 mm |
| Spray equipment | Front spray, rear sprinkler, roof water cannon, self-priming booster pump |
| Cab | Single sleeper, manual air conditioning, mechanical driver seat, MP3/radio, manual cab tilt |
| Max. speed | 100 km/h |
Configuration details and checks
A water truck combines a road chassis with a tank, pump and distribution system. Tank volume alone does not specify pump flow, spray width or suitability for drinking-water transport.
| Tank selection | Confirm nominal and usable volume, tank material, baffles, access openings and the transported water's intended use. |
|---|---|
| Spraying equipment | Specify front spraying, rear spraying, side outlets and any rear water cannon separately. Request a pump flow and pressure specification. |
| Pump connections | Confirm PTO drive, suction and discharge connections, hose lengths, valves and any self-priming requirement. |
What to confirm before ordering
- State whether the truck is for dust suppression, road washing, irrigation or water delivery.
- Request a pump and spraying demonstration with the selected equipment.
- Require suitable materials and approvals if the tank will carry potable water.
Reference examples describe possible equipment, rather than current stock. The written quotation confirms the engine, chassis, body and included equipment for your order.
