SHACMAN X3000 4×2 Tractor Truck SX41854T361C

Catalogue reference · 1 / 5

Before you order

Reference specifications

Confirm the engine, drive, steering side, dimensions, load rating and emissions requirements for your destination before ordering.

SHACMAN X3000 4×2 Tractor Truck SX41854T361C · source specification table 1
MODEL		SX41854T361C
Driver position		Left Hand
Driving type		4*2
Wheelbase/(mm)		3600
Max. Speed/(km/h)		90km/h
Engine	Brand	CUMMINS
	Model	ISME 385 30
	Emission Standard	EURO III
	Rated output power/（PS）	283KW/385HP
	Displacement(L)	10.8L
Transmission	Brand	FAST
	Model	10JSD180
Front axle	Brand	HANDE
	Model	MAN 7.5T
Rear axle	Brand/	HANDE
	Model	16T MAN double reduction driving axle Speed ratio: 4.266
Clutch		￠430 diaphragm clutch
Steering		ZF technology
Frame		（940-850）×300（8）
Suspension		Front and rear multi-leaf spring
Fuel tank		400L Aluminum alloy
Wheels and tires		12R22.5
Brakes		Running brake: Dual circuit compressed air brake
		Parking brake: Air discharging with spring control
		Auxiliary brake: Engine exhaust brake
Cabin		Shaanxi Shacman X3000 extended high top cab with top side air deflector, air master seat, four point air suspension,electric heated rearview mirror, single cooling air conditioning, electric window rocking machine,electric flipping, fiberglass bumper, three-level boarding pedal, central locking (with remote control),multifunctional steering wheel, ordinary air filter, ordinary exhaust, water tank protective grille,JOST 50 saddle, three section integral mudguard, 165Ah maintenance free battery, with circular curtain,sleeper curtain, with rear window, widened sleeper, SHACMAN logo, full English logo, gold logo,iron air storage cylinder, flat installation plate, sunken tail beam, saddle front and rear Adjustable,reverse buzzer, transmission telescopic shaft control, 2 remote keys, Jack Sail compressor, 32T jack.
