Tipper Truck

SHACMAN F3000 8×4 Dump Truck 430hp

Catalogue reference · 1 / 4

Before you order

Reference specifications

Confirm the engine, drive, steering side, dimensions, load rating and emissions requirements for your destination before ordering.

The source summary and detailed table give different model codes. Its 430hp title and 306kW rating also need reconciliation. Confirm the model code and rated power before ordering.

SHACMAN F3000 8×4 Dump Truck 430hp · source specification table 1
Truck Name	Shacman F3000 8×4 Dump Truck 430hp
Transport type	Highway transport
Logistics type	Ore / sand / gravel / coal
Distance(km)	≤200
Road type	Offroad/Paved roads
Drive	8×4
Max weight(t)	≤90
Max speed(km/h)	80
Loaded speed(km)	45~60
Vehicle model	SX3315DV366C
Engine	WP12.430E201
Emission standard	Euro II
Displacement	10.8L
Rated output	306kw
Max.torque	2010N·m
Transmission	12JSD200T-B+QH50
Clutch	430
Frame	850×320(8+7+8)
Front axle	MAN 9.5T
Rear axle	16T MAN double reduction 4.769
Tire	12.00R20
Front Suspension	Multi leaf springs
Rear Suspension	Multi leaf springs
Fuel	Diesel
Capacity of the fuel tank	400L
Battery	180Ah
Dimensions(L×W×H)	9300×2490×3250
Trunk(LxWxH)	7400×2300×1500
Wheelbase	1800+3575+1400
Approach/Departure angle(°)	23/44
Max.gradeability(%)	40
Cab Type	MAN F3000 , mid-lengthened flat roof
Cab Equipments	◆ Rear window ◆ Mechanical clerestory ◆ Hydraulic suspension of cab ◆ Hydraulic driver seat with seatbelts ◆ One sleeping bed ◆ Hydraulic reversal ◆ Radio with MP3 player
Cab Optional	●Air cushioned drivers seat ●Front lamp protection grid ●Oil bath air filter
