R Trucks / Configuration overview
HOWO 8×4 cARGO TRUCK
According to clients’ requirements, we can customize different loading capacity and volume.
WHAT WE OFFER
Sinotruk 8×4 cargo truck
- Condition: Brand New
- Tyre Quantity: 12 tyre
- Engine Power:380hp, 400hp
- Driving Type: 8×4
- Loading capacity: 26000kg
- WhatsApp: +86 159 6303 2117
- E-mail: sales@ruiditemachinery.com
We are always ready to face the most severe working conditions.
Thanks to its robust and durable body, HOWO truck has extraordinary performance in construction, mining and other application scenarios.
In the harsh working environment, HOWO is always ready to meet the severe test.
| Vehicle type | Cargo |
|---|---|
| Drive type | 8x4 |
| Cab | HW76 with AC One sleeper |
| Engine | WEICHAI WP10.380-E22, 380hp, Euro 2 |
| Clutch | Φ430 Diaphragm spring clutch, hydraulic operating with air assistance |
| Transmission | HW19710, 10F /2R |
| Front axle | VGD95, 9.5 Ton Drum brake |
| Rear axle | MCX16ZG |
| Steering System | ZF power steering, model ZF8118, hydraulic steering with power assistance |
| Brake System | Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake |
| Electrics | Single wire, 24 V, negative grounded; Alternator: 1540W; Start Motor:7.5kW;Battery:2*12V/165Ah |
| Tyre | 12.00R20,315/80R22.5,13R22.5 etc. |
| Fuel Tank (L) | 300L Diesel Tank |
| Overall Dimension | 9600*2550*3200mm |
| Max. Speed (km/h) | 85 |
| Steel thickness of Carriage(mm) | Floor:3mm/ Side: 1.5mm, Q235 plate |
| The carriage Size | 7000x2300x800mm |
Hot Selling Model Of Howo Dump Truck
Hot Selling Model Of Howo Dump Truck
improve your business
Let’s discuss how we can help you.
GET QUOTE
R Trucks reference configuration
The catalogue above includes configuration variants. The tables below are references for comparing offers. Confirm the actual engine, gearbox, axles, dimensions, equipment and steering side in writing, and match the inspection record to the truck supplied.
| Engine | Weichai WP12S400E201 · 400 hp |
|---|---|
| Drive | 8x4 |
| Gearbox | HW19710 + HW70 PTO |
| Cargo body | 9.65 m stake body (van body to order) |
| ABS | 4S/4M |
| Model | ZZ1317V4667B1 |
|---|---|
| Driver position | Left- or right-hand drive |
| Engine | Weichai WP12S400E201, 400 hp, Euro II |
| Cab | HW76 cab, new front |
| Gearbox | SINOTRUK HW19710 with HW70 flange-type power take-off |
| Front axles | SINOTRUK VGD95 × 2, drum brakes |
| Rear axles | SINOTRUK MCX16ZG, drum brakes, ratio 4.803 |
| Steering | Bosch power steering |
| ABS | 4S/4M |
| Tyres | 12.00R20, mixed tread, 18PR |
| Fuel tank | 400 L |
| Cargo body | DONGYUE 9.65 m stake (fence) body with gates |
| Equipment | Air-intake pre-cleaner, Parker fuel pre-filter, rear towing hook, vertical exhaust, reversing alarm, fire extinguisher, English instrument panel, battery box lock |
Configuration details and checks
The listed 8x4 cargo build has a 9.65 m DONGYUE stake body; an enclosed van body is an option. Dropside gallery images illustrate another body style and do not replace the ordered stake or van specification.
| Engine and gearbox | WP12S400E201 400 hp engine and HW19710 gearbox with HW70 PTO on the listed ZZ1317V4667B1 build. |
|---|---|
| Axles and brakes | Two VGD95 front axles, MCX16ZG rear axles with a 4.803 ratio, and 4S/4M ABS are listed. |
| Body definition | Specify stake, dropside or enclosed van body, together with body length, opening dimensions, floor construction and load restraints. |
What to confirm before ordering
- Confirm finished overall dimensions and actual unladen weight for the chosen body.
- Check that the chassis drawing and photographs show four axles.
- Obtain a loading plan for heavy or unevenly distributed cargo.
Reference examples describe possible equipment, rather than current stock. The written quotation confirms the engine, chassis, body and included equipment for your order.
